Terex Manlift Specifications
Terex is a Westport, Connecticut company which specializes in making in manufacturing construction machines. Equipment such as manlifts, boom lifts and aerial lifts. These kinds of machines are designed to facilitate access to hard to reach areas, large equipment, roofs and buildings, among other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt moves only in one direction and includes steps or handholds or paltforms that are attached to the unit to be able to move workers from every floor.
TB85
Terex's TB85 man lift offers a max working height at 91 feet. The max height of the platform reaches 85 feet, whilst the model's maximum width is 8.5 feet. The TB85 has dimensions which measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This model offers a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal measuring 75 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall measures at 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
